This is security camera system monitoring at its best. This is SureVision.
4K Ultra Definition with SureVision Security Camera
Included in the package is our top-tier SureVision 4K Ultra Definition professional security camera. This 8-megapixel 4K bullet-style camera carries high-end, next-generation features. Its 110-degree wide-angle lens offers expansive coverage, while both infrared night vision and LED spotlight mode ensure detailed imaging even in the darkest hours. Ideal for any environment, the camera settings can be adjusted for specific applications or preferred illumination types. The built-in microphone provides you to option to employ two-way audio capability from your smartphone via our mobile app, allowing you to communicate as needed.
Active Deterrence with Advanced AI features
These security cameras come with a feature known as Active Deterrence. It has a loud siren and LED strobe lights that can be activated when motion is detected, discouraging potential threats. The Ultra Motion Detection (UMD) feature utilizes sophisticated AI to trigger motion specifically on human and/or vehicle movements. This feature ensures highly accurate alerts, minimizing the risk of false alarms.
Direct notifications can be sent to your mobile devices, ensuring you are informed about every important event in real time. Employing WDR technology to tackle glare effects from intense lighting and the advanced H.265 high video compression for enhanced storage capability, this camera represents an excellent choice for exceptional image quality and comprehensive security.
If looking for a truly superior camera, look no further than this active deterrent bullet camera! Order this in-stock product online today!
Want to learn more about our top rated security systems? Talk to us at 888.653.2288.
*Always use SureVision cameras with SureVision NVR units for full-featured use and functionality.

Looking for a complete IP camera system?
Check out our Green Line Series
IP Security Camera Systems.

Looking for a network video recorder for this camera?
Check out our compatible
Green Line Network
Video Recorders.
TECHNICAL SPECIFICATIONS | |||||||||
---|---|---|---|---|---|---|---|---|---|
Camera | |||||||||
Sensor | 1/2.8", 8.0 megapixel, progressive scan, CMOS | ||||||||
Minimum Illumination | Colour: 0.003Lux (F1.6, AGC ON) 0Lux with IR on | ||||||||
Day/Night | IR-cut filter with auto switch (ICR) | ||||||||
Shutter | Auto/Manual, 1 ~ 1/100000s | ||||||||
Adjustment angle | Pan: 0° ~ 360° | Tilt: 0° ~ 80° | Rotate: 0° ~ 360° | ||||||
WDR | 120dB | ||||||||
S/N | >56dB | ||||||||
Lens | |||||||||
Lens | 2.8mm@F1.6 | 4.0mm@F1.6 | |||||||
Angle of View (H) | 106.7° | 87.5° | |||||||
Angle of View (V) | 57.1° | 46.3° | |||||||
Angle of View (O) | 115.7° | 92.4° | |||||||
DORI | |||||||||
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) | ||||
2.8 | 86.0 | 34.8 | 17.4 | 8.7 | |||||
4.0 | 124.1 | 49.7 | 24.8 | 12.4 | |||||
Illuminator | |||||||||
IR Range | Up to 30m (98 ft) IR range | ||||||||
Wavelength | 850nm | ||||||||
IR On/Off Control | Auto/Manual | ||||||||
Video | |||||||||
Video Compression | Ultra 265, H.265, H.264, MJPEG | ||||||||
H.264 code profile | Baseline profile, Main profile, High profile | ||||||||
Frame Rate | Main Stream: 8MP (3840*2160), Max 20fps; 5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; 640*360,Max 30fps; D1 (720*576), Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
||||||||
Video Bit Rate | 128 Kbps~16 Mbps | ||||||||
U-code | Support | ||||||||
ROI | Up to 8 areas | ||||||||
Video Stream | Triple streams | ||||||||
OSD | Up to 8 OSDs | ||||||||
Privacy Mask | Up to 4 areas | ||||||||
Image | |||||||||
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | ||||||||
Image Setting | Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser | ||||||||
Digital Noise Reduction | 2D/3D DNR | ||||||||
Smart IR | Support | ||||||||
Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise | ||||||||
Dewarping | Supported | ||||||||
HLC | Supported | ||||||||
BLC | Supported | ||||||||
Defog | Digital Defog | ||||||||
Intelligent | |||||||||
Smart intrusion prevention | Support false alarm filtering: Line crossing detection, Intrusion detection, Region entrance detection, Region exit detection | ||||||||
Face capture | Support | ||||||||
Statistical Analysis | People counting, support tripwire people counting and area people counting | ||||||||
Events | |||||||||
Basic Detection | Motion detection, tampering alarm, audio detection | ||||||||
General Function | Watermark, IP address filtering, tampering alarm, access policy, ARP protection, RTSP authentication, user authentication | ||||||||
Audio | |||||||||
Audio Compression | G.711 | ||||||||
Audio Bitrate | 64 Kbps | ||||||||
Two-way audio | Supported | ||||||||
Suppression | Supported | ||||||||
Sampling Rate | 8KHZ | ||||||||
Storage | |||||||||
Edge Storage | Micro SD, up to 256GB | ||||||||
Network Storage | ANR, NAS(NFS) | ||||||||
Network | |||||||||
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS, SSH | ||||||||
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API,SDK | ||||||||
User/Host | Up to 32 users. 2 user levels: administrator and common user | ||||||||
Security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF | ||||||||
Client | EZStation EZView EZLive |
||||||||
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | ||||||||
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | |||||||||
Interface | |||||||||
Audio I/O | N/A | ||||||||
Alarm I/O | N/A | ||||||||
RS485 | N/A | ||||||||
Built-in Mic | Supported | ||||||||
Built-in Speaker | Supported | ||||||||
WIFI | N/A | ||||||||
Network | 1 RJ45 10M/100M Base-TX Ethernet | ||||||||
Video Output | N/A | ||||||||
Certifications | |||||||||
EMC | FCC CFR 47 Part 15 EN 55032:2015 EN 55024:2010 EN 61000-3-2:2014 EN 61000-3-3-2013 |
||||||||
Safety | IEC 62368-1 EN 62368-1 UL 62368-1 |
||||||||
Environment | CE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006) | ||||||||
General | |||||||||
Power | DC 12V±25%, PoE (IEEE 802.3af) | ||||||||
Power consumption: Max 10.5W | |||||||||
Power Interface | Ø 5.5mm coaxial power plug | ||||||||
Dimensions (L × W × H) | Φ111 x 95mm (Φ4.4” x 3.7”) | ||||||||
Weight | 0.48kg (1.058lb) | ||||||||
Material | Metal + Plastic | ||||||||
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | ||||||||
Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | ||||||||
Surge Protection | 4KV | ||||||||
Reset Button | N/A | ||||||||
Protection | Ingression protection: IP67 |
CAMERA FEATURES
- 4K IP Camera (3840 x 2160)
- 2.8mm Lens (110° Wide Angle View)
- Up to 100ft Infrared Night Vision
- Built-in Microphone and Speaker
- Starlight - low light performance
- H.265 Video Compression
- Weatherproof - Indoor/Outdoor (IP67)
- Wide Dynamic Range - WDR (120dB)
- Power Over Ethernet - PoE
- Measurement: 3.7" H x 4.6" D
Approximate Distances:
Identify (Up to 28ft)
Recognize (Up to 57ft)
Detect (Up to 285ft)
