Power Over Ethernet
Improve network agility and scalability with the proven CSP-POEINJECTOR from CCTV Security Pros. This high-quality power over ethernet injector eliminates the need to place your IP security cameras near a power outlet. Plug the injector into an easily accessible power outlet and enjoy dependable power and video transmission over your cable runs.
The CSP-POEINJECTOR comes complete with everything you need to expand your surveillance system, including a PoE injector adapter and a power supply. This ready-to-go Power Over Ethernet injector makes it easy to deliver power to your IP cameras over a single CAT5 cable.
- Gigabit 30W PoE Injector
- Input Voltage: 100-240VAC
- Output Voltage :48VDC
- Network standards: IEEE802.3i 10 BASE-T, IEEE802.3i 100 BASE-TX, IEEE802.3x flow control, IEEE802.3af /IEEE802.3at
- PoE power: 30W Cable: UTP cat.5 or higher Internal power adapter
- Processing types: Store-and-forward, Half-duplex backpressure, and IEEE802.3X full-duplex flow control
- Power pin: 1 2 + 3 6-
- Data Rate: 10/100/1000Mbps
- Plug and play installation
- Midspan automatically detects all devices support for PoE
- Working Tem.: 0℃-40℃
- Storage Tem.: -10℃-70℃
- Operating Humidity: 20％-85％
