SUREVISION 16 Camera 4MP Complete Indoor/Outdoor Vandal Dome IP System (Black)

Model: SV-16IPTD4-B
SUREVISION 16 Camera 4MP Complete Indoor/Outdoor Vandal Dome IP System (Black)

Select your options:

$7,299.99 $4,299.99
(You save $3,000.00)
superior products 3 year warranty
live usa technical support
30 day money back guarantee
free shipping on all orders over $100

SUREVISION 16 Channel 4MP NVR Security Camera System

When it comes to securing large or expansive properties like retail stores, shopping malls, warehouses, small schools, or even large homes, choosing the right security camera system and network video recorder (NVR) matters. We bring you our advanced SUREVISION 4MP (Megapixel) 16 channel NVR security camera system, which features real-time recording, sufficient storage space, full HD resolution, mobile surveillance support, and other superior features to suit your security needs.

Designed for Indoor and Outdoor Use

Whether you want to monitor indoor or outdoor areas, our SUREVISION security cameras are designed with metal housing and vandal-proof dome camera covers to ensure maximum protection against vandalism. Our systems feature infrared night vision of up to 100ft in complete darkness, and the dome cameras provide wide-angle viewing, so you can be confident you’ll be able to access excellent surveillance day and night.

If you’re looking for a tough and durable 16 channel NVR security camera system with vandal-proof features for your business or other property, look no further than our SUREVISION IP security systems. The 4MP IP dome cameras deliver clearer and sharper images and video, greater zooming capability, intelligent motion trigger and alert function, and IP67 weatherproof protection. The complete system is easy to install and has no monthly subscription fees.

The complete 16 channel security system includes:

  • (1) 16 Channel SUREVISION HD NVR
  • (1) 3 TB Surveillance-Grade Hard Drive (installed)
  • (16) 4MP IP Infrared Dome Security Cameras with a Night Vision Range of Over 100 ft
  • (16) 100 ft CAT5 Cables
  • High Definition LCD Monitor - INCLUDED
  • Quick Start Guide
  • Free Remote Viewing Software and Apps
  • Video Surveillance Warning Stickers and Aluminum Sign

*Always use SUREVISION cameras with SUREVISION NVR units for full-featured use and functionality.

Browse our all-new commercial-grade 16 channel NVR security camera systems at CCTV Security Pros to find the best system to match your needs and budget.

Order Online Now

With over 60,000 satisfied customers relying on our security solutions, you can shop with confidence at CCTV Security Pros. We provide free unlimited USA tech support so you can get all the help you need when installing your system. Our DIY systems save you thousands of dollars in installation costs. We also back all purchases with a full 3-year warranty, free shipping, and a 100% money-back satisfaction guarantee.

Take advantage of our latest IP technology by ordering our most advanced and top-selling 16 channel NVR security camera systems online. Have any questions? Contact us now.

About the Security Cameras

  • Day/night functionality
  • Smart IR, up to 30 m (98 ft) IR distance
  • 3D DNR (Digital Noise Reduction)
  • Ultra 265, H.265, H.264, MJPEG
  • ROI (Region of Interest)
  • ONVIF conformance
  • Wide temperature range: -30°C to 60°C (-22°F to 140°F)
  • Wide voltage range of ±25%
  • IP67 waterproof
  • 3-axis mechanism (pan / tilt / zoom)
Technical Specification

Camera
Sensor 1/3", 4.0 megapixel, progressive scan, CMOS
Lens 2.8mm@F2.0
DORI Distance Lens Detect(m) Observe(m) Recognize(m) Identify(m)
2.8mm 42 16.8 8.4 4.2
4.0mm 60 24 12 6
Angle of view(H) 104.4° 78.9°
Angle of View (V) 54.4° 39.6°
Angle of View (O) 135.7° 97.0°
Shutter Auto/Manual, 1~1/100000 s
Adjustment angle Pan:   0°~360° Tilt:   0°~90° Rotate: 0°~360°
Min. Illumination Colour: 0.03 Lux (2.0, AGC ON)
0 Lux with IR
IR Range Up to 30m (98 ft) IR range
Day/Night IR-cut filter with auto switch (ICR)
S/N >52dB
WDR DWDR
Noise Reduction 2D/3D
Video
Video Compression Ultra 265,H.265,H.264,MJPEG
H.264 code profile Baseline profile, Main Profile
Frame Rate Main Stream:4MP (2592*1520): Max. 20 fps;
Sub Stream:720P (1280*720): Max. 20 fps;
Third Stream:D1 (720×576): Max. 20 fps
HLC Supported
BLC Supported
OSD Up to 4 OSDs
Privacy Mask Up to 8 areas
ROI Up to 2 areas
Motion Detection Up to 4 areas
Network
Protocols IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP, RTP,RTSP,RTCP,DNS,DDNS,NTP,FTP,UPnP,HTTP,HTTPS,SMTP, SSL
Compatible Integration ONVIF(Profile S,Profile T),API
Interface
Network 10/100M Base-TX Ethernet
General
Power 12 V DC±25%, PoE (IEEE802.3 af)
Power consumption: Max 4W
Dimensions (Ø x H) Φ118x 96 mm (Φ4.6” x 3.8”)
Weight 0.35kg (0.77lb)
Working Environment -30°C ~ +60°C (-22°F ~ 140°F), Humidity :10%~90% RH(non-condensing)
Ingress Protection IP67



About the Network Video Recorder

  • 16 channel input
  • Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
  • Up to 12 Megapixels resolution recording
  • Supports Ultra 265/H.265/H.264 video formats
  • Plug & Play with up to 16 independent PoE (Power over Ethernet) network interfaces
  • 4 SATA HDDs, Up to 10TB for each HDD
  • Various fisheye dewarping modes for live view and playback for both web interface and GUI
  • ANR technology to enhance storage reliability when the network is disconnected
  • Supports cloud upgrade
Technical Specification

Video/Audio Input
IP Video Input 16-ch 32-ch
Two-way Audio Input 1-ch, RCA
Network
Incoming Bandwidth 160Mbps 320Mbps
Outgoing Bandwidth 320Mbps
Remote Users 128
Protocols P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
HDMI/VGA output HDMI1/VGA:
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
HDMI2:
4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
Recording Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output 1-ch, RCA
Synchronous Playback 16-ch
Corridor Mode Screen 3/4/5/7/9/10/12/16 3/4/5/7/9/10/12/16/32
Decoding
Decoding format Ultra 265, H.265, H.264
Live view/Playback 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability 3 x 12MP@25, 4 x 4K@30, 8 x 4MP@30, 16 x 1080p@30, 32 x 960p@25
Hard Disk
SATA 4 SATA interfaces
Capacity up to 10TB for each HDD
Smart
VCA Detection Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking
VCA Search Face search, Behavior search
Statistical Analysis People counting
External Interface
Network Interface 1 RJ45 10M/100M/1000M self-adaptive Ethernet Interface
Serial Interface 1 x RS485
USB Interface Front panel: 2 x USB2.0
Rear panel: 1 x USB3.0
Alarm In 16-ch
Alarm Out 4-ch
Power Output 12 VDC
PoE
Interface 16 independent 100 Mbps PoE network interfaces
Max Power Max 30W for single port
Max 200W in total ( 12.5W for each )
Supported Standard IEEE 802.3at
General
Power Supply 100 ~ 240 VAC
Power Consumption: ≤ 20 W( without HDD )
Working Environment -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H) 442 mm× 425mm×86mm (17.4" × 16.7"×3.4"  )
Weight ( without HDD ) ≤ 5.24 Kg ( 11.55 lb )
NVR FEATURES
  • 4K Ultra High Definition
  • 16 PoE Camera Inputs
  • Remote Viewing – No Monthly Fees
  • H.265 High Video Compression
  • 160 Mbps Incoming Bandwith
  • HDMI and VGA Display Output
  • 4 Hard Drive Bays
CAMERA FEATURES
  • 4 Megapixel IP Camera (2688×1520)
  • 2.8mm Lens (110° Wide Angle View)
  • Up to 100ft Infrared Night Vision
  • H.265 Video Compression
  • Weatherproof - Indoor/Outdoor(IP67)
  • Wide Dynamic Range (120dB)
  • Power Over Ethernet - PoE
  • Measurement: 3.8" H x 4.6" D
Approximate Distances:
Identify (Up to 14ft)
Recognize (Up to 28ft)
Detect (Up to 138ft)
