B-Stock Products

B-Stock products offer outstanding value and performance. These items were previously returned by customers and cannot be sold as new. Although many of these cameras appear like new as depicted in their respective images, some have been briefly mounted or may show signs of light use. Please note that original packaging is not always included.

Every B-Stock product is inspected, tested, and factory restored to meet the same performance and reliability standards as a brand-new model. Our B-Stock products are backed by a 90-day limited warranty.

Security Camera Technical Specifications

Camera
Model	SV-PTZ5X-N
Maximum Resolution	5MP
Image Sensor	1/2.7" CMOS
Minimum Illumination	Color: 0.005 Lux (F1.2, AGC ON); 0 Lux with IR
Day / Night	IR-Cut Filter with Auto Switch (ICR)
Shutter	Auto / Manual, 1 to 1/100000s
Wide Dynamic Range	120dB WDR
S/N Ratio	>56dB
Lens
Focal Length	2.7mm to 13.5mm
Optical Zoom	5×
Iris	F1.2
Horizontal Field of View	106.9° to 30.6°
Vertical Field of View	56° to 17.7°
Diagonal Field of View	131.5° to 36.1°
DORI Distance
Detect	70.9m to 247.5m (232.5 ft to 812.0 ft)
Observe	28.4m to 99.0m (93.2 ft to 324.8 ft)
Recognize	14.2m to 49.5m (46.5 ft to 162.4 ft)
Identify	7.1m to 24.8m (23.3 ft to 81.4 ft)
Illuminator
Infrared Illumination Distance	Up to 50m (164 ft)
Warm Light Illumination Distance	Up to 15m (49.2 ft)
Wavelength	850nm
Light On / Off Control	Auto / Manual
Smart IR	Supported
Video
Video Compression	Ultra 265 / H.265 / H.264 / MJPEG
Main Stream	5MP (2880 × 1620), Max. 30fps
Sub Stream	720P (1280 × 720), Max. 30fps
Third Stream	D1 (720 × 576), Max. 30fps
Video Bit Rate	128 Kbps to 16 Mbps
U-Code	Supported
Region of Interest (ROI)	Supported
Video Streams	Triple Streams
OSD	Up to 8 OSDs
Privacy Mask	Up to 4 Areas
Intelligent Features
Auto Tracking	Supported; Target Filtering: Human Only
Smart Intrusion Prevention	Cross Line Detection, Intrusion Detection, Enter Area Detection and Leave Area Detection; supports false alarm filtering and classification of humans, non-motor vehicles and vehicles
People Counting	Supports People Flow Counting and Crowd Density Monitoring
Exception Detection	Object Removed, Object Left Behind, Scene Change and Defocus Detection
Basic Detection	Motion Detection, Tampering Alarm, Audio Detection, Object Removed, Object Left Behind, Scene Change and Defocus Detection
General Functions	Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication and User Authentication
White Balance	Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
Digital Noise Reduction	2D / 3D DNR
Image Flip	Normal / Flip Vertical / Flip Horizontal / 180°
HLC	Supported
BLC	Supported
Smart IR	Supported
Defog	Digital Defog
Audio
Built-In Microphone	Supported
Built-In Speaker	Supported
Audio Compression	G.711U / G.711A
Audio Bit Rate	128 Kbps
Two-Way Audio	Supported
Audio Suppression	Supported
Sampling Rate	16kHz
Storage
Edge Storage	MicroSD Card, Up to 512GB
Network Storage	ANR / NAS (NFS)
Network
Protocols	TLS 1.3 / SSH / IGMP / RTP / RTCP / SMTP / IPv4 / IPv6 / ICMP / ARP / TCP / UDP / DHCP / PPPoE / RTSP / RTMP / DNS / DDNS / NTP / FTP / UPnP / HTTP / HTTPS / 802.1x / SNMP / QoS / SSL/TLS
Compatible Integration	ONVIF Profile S / Profile G / Profile T / Profile M / API / SDK
Security	Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
Client	EZStation / UNV-Link / UNV-Link Pro
Web Browser	Plug-In Required Live View: IE 10 and Above, Chrome 45 and Above, Firefox 52 and Above, Edge 79 and Above
Network Interface	1 × RJ45 10M/100M Base-TX Ethernet
PTZ
Pan Range	0° to 345°
Tilt Range	-10° to 100°
Pan Speed	1°/s to 50°/s
Tilt Speed	1°/s to 40°/s
Preset Patrol	16 Patrols, Up to 64 Presets for Each Patrol
Patrol Stay Time	120s to 1800s
Home Position	Supported
Interface
Audio Input	1 Input: Impedance 1kΩ, Amplitude 2.5V [p-p]
Audio Output	1 Output: Impedance 600Ω, Amplitude 2.5V [p-p]
Alarm I/O	1 Input / 1 Output
Built-In Microphone	Supported
Built-In Speaker	Supported
Network	1 × RJ45 10M/100M Base-TX Ethernet
Certifications
EMC	CE-EMC (EN 55032:2015+A11:2020+A1:2020, EN 50130-4:2011+A1:2014, EN 61000-3-3:2013+A1:2019+A2:2021, EN IEC 61000-3-2:2019+A1:2021)
Safety	CE LVD (EN 62368-1:2020+A11:2020); UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environmental Compliance	CE-RoHS (2011/65/EU; (EU) 2015/863)
Ingress Protection	IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)
Power & Environmental
Power	12V DC (±25%) / PoE+ (IEEE 802.3at)
Power Consumption	18W
Power Interface	Ø5.5mm Coaxial Power Plug
Working Environment	-30°C ~ 60°C (-22°F ~ 140°F) Humidity: ≤95% RH (Non-Condensing)
Storage Environment	-40°C ~ 70°C (-40°F ~ 158°F) Humidity: ≤95% RH (Non-Condensing)
Surge Protection	2kV
Reset Button	Supported
Heater	Supported
Configurable P/N	Supported
Construction
Dimensions	185 × 133 × 286mm (7.3" × 5.2" × 11.3") (L × W × H)
Weight	1.32kg (2.91 lb)

CAMERA FEATURES

5 Megapixel PTZ IP Security Camera – Up to 2880 × 1620 at 30fps
2.7–13.5mm Lens
5× Optical Zoom
106.9° to 30.6° Horizontal Field of View
Motorized Pan & Tilt
Human Auto Tracking
Smart Intrusion Prevention
Human, Vehicle and Non-Motor Vehicle Classification
Cross Line Detection
Intrusion Detection
Enter / Leave Area Detection
People Flow Counting & Crowd Density Monitoring
Object Removed & Object Left Behind Detection
Scene Change & Defocus Detection
Up to 164 ft Infrared Illumination
Up to 49.2 ft Warm Light Illumination
0.005 Lux Minimum Color Illumination
Built-In Microphone & Speaker
Two-Way Audio
120dB Wide Dynamic Range (WDR)
Ultra 265 / H.265 / H.264 Video Compression
Triple Video Streams
2D / 3D Digital Noise Reduction
Smart IR
Digital Defog
MicroSD Card Storage – Up to 512GB
ONVIF Compatible – Profiles S, G, T and M
PoE+ (IEEE 802.3at)
12V DC Power Option
Weather Resistant – IP66
Built-In Heater
2kV Surge Protection
Dimensions: 7.3" L × 5.2" W × 11.3" H
Weight: 2.91 lb

Approximate Distances

Identify: Approximately 23 ft to 81 ft
Recognize: Approximately 47 ft to 162 ft
Observe: Approximately 93 ft to 325 ft
Detect: Approximately 233 ft to 812 ft
