B-Stock Products

B-Stock products offer outstanding value and performance. These items were previously returned by customers and cannot be sold as new. Although many of these cameras appear like new as depicted in their respective images, some have been briefly mounted or may show signs of light use. Please note that original packaging is not always included.

Every B-Stock product is inspected, tested, and factory restored to meet the same performance and reliability standards as a brand-new model. Our B-Stock products are backed by a 90-day limited warranty.

Camera Specifications

Camera
Image Sensor	1/2.7" CMOS
Effective Pixels	2592 × 1944, 5MP
Scanning System	Progressive
Electronic Shutter Speed	PAL: 1/25 ~ 1/100000s NTSC: 1/30 ~ 1/100000s
Minimum Illumination	0.02 Lux/F1.85, 30IRE; 0 Lux with IR on
S/N Ratio	More than 65dB
IR Distance	Up to 30 m (98 ft)
IR On/Off Control	Auto / Manual
IR LEDs	1
Lens
Lens Type	Fixed lens / Fixed iris
Mount Type	Board-in
Focal Length	3.6mm (2.8mm, 6mm Optional)
Max Aperture	F1.85
Angle of View	Horizontal: 77.5° (93° / 49°)
Focus Control	N/A
Close Focus Distance	1400mm (800mm / 2800mm) 55" (31.5" / 110")
DORI Distance
Note: The DORI distance is a "general proximity" of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specifications and lab test results according to EN 62676-4, which defines the criteria for Detect, Observe, Recognize and Identify respectively.
Detect – 25px/m (8px/ft)	2.8mm: 56 m (184 ft) 3.6mm: 80 m (262 ft) 6mm: 120 m (394 ft)
Observe – 63px/m (19px/ft)	2.8mm: 22 m (72 ft) 3.6mm: 32 m (105 ft) 6mm: 48 m (157 ft)
Recognize – 125px/m (38px/ft)	2.8mm: 11 m (36 ft) 3.6mm: 16 m (53 ft) 6mm: 24 m (79 ft)
Identify – 250px/m (76px/ft)	2.8mm: 6 m (21 ft) 3.6mm: 8 m (26 ft) 6mm: 12 m (39 ft)
Pan / Tilt / Rotation
Adjustment Range	Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360°
Video
Resolution	5MP (2592 × 1944)
Frame Rate	20fps @ 5MP 25/30fps @ 4MP 25/30fps @ 1080P
Video Output	1-channel BNC high-definition video output / CVBS video output (switchable)
Day/Night	Auto (ICR) / Manual
OSD Menu	Multi-language
BLC Mode	BLC / HLC / DWDR
WDR	DWDR
Gain Control	AGC
Noise Reduction	2D
White Balance	Auto / Manual
Smart IR	Auto / Manual
Certifications
Certifications	CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 Subpart B, ANSI C63.4-2014) UL (UL60950-1 + CAN/CSA C22.2 No.60950-1)
Interface
Audio Interface	N/A
Electrical
Power Supply	12V DC ±30%
Power Consumption	Max. 3.7W (12V DC, IR on)
Environmental
Operating Conditions	-40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH Start-up should be done at above -40°C (-40°F).
Storage Conditions	-40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
Ingress Protection	IP67
Construction
Casing	Aluminium
Dimensions	176 × 72.4 × 72.5 mm (6.93" × 2.85" × 2.85")
Net Weight	0.37 kg (0.82 lb)
Gross Weight	0.48 kg (1.06 lb)

CAMERA FEATURES

5 Megapixel HD-CVI Camera (2592 × 1944)
2.8mm Lens (110° Wide Angle View)
Up to 100 ft Infrared Night Vision
Weatherproof – Indoor/Outdoor (IP67)
12 Volt DC
Measurements: 6.93" L × 2.85" W × 2.85" H

Approximate Distances

Identify: Up to 21 ft
Recognize: Up to 36 ft
Detect: Up to 184 ft
