SUREVISION IP Camera NVRs
Network Video Recorders are the most important part of any high quality IP surveillance system. Take advantage of our high-end, commercial-grade SUREVISION IP Camera NVRs at CCTV Security Pros to enjoy HD video quality live over the internet. Our full-featured and affordable IP camera recorders now offer up to 4K video resolution with multiple hard drive options that can be expanded for a flexible solution that fits your surveillance recording needs. Our SUREVISION IP NVR line is ONVIF compatible. SUREVISION is our latest and greatest line of IP Cameras. Order a SUREVISION IP NVR and treat yourself to a crystal clear, user friendly video recorder. View your cameras over the Internet, tablets, and cell phones as easy as 1-2-3.
SUREVISION "Green Line" Video Surveillance Recorder Highlights:
- Remote Viewing on PC, Cell Phone, and Tablet
- Industry Latest and Greatest
- Up to 4K Recording and Playback
- Motion 24/7 or on Motion Detection Mode
- Quick Start Guide Included for Easy Set Up
- 3 Year Warranty
- ONVIF Compliant
- Free Unlimited USA Support
*Always use SureVision cameras with SureVision NVR units for full-featured use and functionality.
Features
- Support Ultra 265/H.265/H.264 video formats
- 4-channel input
- Plug & Play with 4 independent PoE network interfaces
- Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
- Support 1-ch HDMI, 1-ch VGA
- HDMI and VGA simultaneous output
- 1 SATA HDD up to 10 TB
- Support cloud upgrade
TECHNICAL SPECIFICATIONS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Model | SV-NVR1P4-N | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video/Audio Input | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IP Video Input | 4-ch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Two-way Audio Input | 1-ch, RCA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Incoming Bandwidth | 80Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Outgoing Bandwidth | 64Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Remote Users | 128 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocols | P2P, UPnP, NTP, DHCP, PPPoE | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video/Audio Output | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDMI/VGA Output | HDMI: 3840x2160/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recording Resolution | 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | 1-ch, RCA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Synchronous Playback | 4-ch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Corridor Mode Screen | 3/4 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding format | Ultra 265/H.265/H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Liveview/Playback | 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Capability | 1 x 4K@30, 1 x 5MP@30, 2 x 4MP@30, 2 x 3MP@30, 4 x 1080P@30 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hard Disk | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SATA | 1 SATA interface | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Capacity | up to 6TB for each disk | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
External Interface | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface | 4 RJ45 10M/100M self-adaptive Ethernet Interface | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max Power | Max 30W for single port Max 54W in total |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Supported Standard | IEEE 802.3at, IEEE 802.3af | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 48V DC Power Consumption: ≤9 W (without HDD) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Environment | -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions (W×D×H) | 260mm × 240mm × 47mm (10.2"×9.4"×1.9 ") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight (without HDD) | 1kg (2.20 lb) |
NVR FEATURES
- 4K Ultra High Definition
- 4 PoE Camera Inputs
- Remote Viewing – No Monthly Fees
- H.265 High Video Compression
- 80 Mbps Incoming Bandwidth
- HDMI and VGA Display Output
- 1 Hard Drive Bay
