SureVision 16 Channel 4K PoE NVR Recorder with Included 4TB Storage
The SureVision SV-NVR2P16-N is a professional 16-channel network video recorder built to record, manage, and protect video from up to 16 compatible IP security cameras. It combines 16 built-in PoE camera ports, 320 Mbps incoming bandwidth, 4K HDMI output, dual hard-drive bays, advanced playback and event-search tools, and private local recording with no required monthly cloud-storage fees.
Every SV-NVR2P16-N includes a pre-installed 4TB surveillance-grade hard drive, so the recorder arrives ready to store footage locally. It is designed for businesses, warehouses, schools, churches, government facilities, larger homes, and other properties that need dependable multi-camera surveillance, remote viewing, flexible storage, and room to grow.
No Fees. Private Recording.
- Pre-installed 4TB surveillance-grade hard drive
- No subscriptions or cloud fees
- 24/7 continuous recording ready
- Dual hard drive support for expanded storage
- RAID 1 supported with a second compatible drive
Fast & Easy Setup
- Plug-and-play with compatible SureVision cameras
- 16 built-in PoE ports for direct camera connection
- Scan QR code for mobile viewing
- System ready out of the box
- Works for both DIY users and professional installers
Professional Features
- Remote viewing on phone and desktop
- Advanced playback and export tools
- 8 alarm inputs and 2 alarm outputs
- Supports PTZ, zoom, analytics, and specialty cameras
- Built for business, commercial, and serious home use
SureVision Professional Surveillance — Built for Real Protection
More Than Just Recording — A Complete Professional Security Platform
Unlike consumer security cameras that rely on subscriptions and limited features, SureVision systems are engineered for serious users who demand control, reliability, and long-term value.
No Monthly Fees — Ever
- 100% local recording to your private hard drive
- No cloud dependency, no subscriptions, no hidden costs
- Your footage stays secure, private, and in your control
Built-In Professional Monitoring Tools
Every system includes powerful tools typically locked behind paywalls:
- Smart motion detection & alerts
- Remote viewing (mobile + desktop)
- Playback, search, and event filtering
- Multi-camera live view dashboards
- Export and evidence backup tools
No additional software required — it’s all built in.
Private, Secure Storage — Installed & Ready
- Includes one pre-installed 4TB surveillance-grade hard drive
- Designed for 24/7 continuous recording
- Dual SATA bays for expanded storage
- Supports up to 24 TB for each HDD
- RAID 1 supported when a second compatible drive is installed
- Ideal for businesses that need longer retention periods
Use It Your Way — Simple or Advanced
- Works out of the box with no video management software required
- For advanced users, supports integration with platforms like Blue Iris
- Flexible enough for both DIY users and professional installers
Professional-Grade Hardware
- 3-Year Warranty
- Built for 24/7 operation
- 16 built-in PoE ports for direct camera connection
- 8 alarm inputs and 2 alarm outputs
- Reliable performance where failure is not an option
Certified & Trusted
- National Defense Authorization Act Compliant messaging supported across the SureVision platform
- Underwriters Laboratories Listed
- Open platform compatibility for broader integration flexibility
Advanced Camera Capabilities
- Supports motorized zoom (varifocal) cameras for precise coverage
- Supports PTZ control for active monitoring
- Supports smart detection features on compatible cameras
- Supports face detection, face comparison, vehicle detection (LPR), temperature detection, SIP, UMD, video metadata, and traffic monitoring on compatible cameras
- Supports color night vision, infrared, wide-angle, long-range, and specialty camera options
Built to Grow With You
- Supports up to 16 IP cameras
- Built for larger homes, offices, warehouses, schools, and growing businesses
- Stronger bandwidth and storage flexibility than smaller recorders
- Designed for long-term investment, not replacement
Why Professionals Choose SureVision
- No fees. Ever.
- Full control of your system and data
- Built for reliability, not shortcuts
- Trusted by businesses, installers, and government buyers
- Backed by real experts — not outsourced support
Bottom Line
If you want a recorder that simply stores video, there are cheaper options.
If you want a professional surveillance platform with 16-channel capacity, 320 Mbps incoming bandwidth, a pre-installed 4TB hard drive, smarter search tools, and expandable storage, the SV-NVR2P16-N is built for that.
Plug-and-Play with SureVision Cameras
This SureVision NVR is designed to work directly with compatible SureVision IP cameras for a true plug-and-play experience. Connect your cameras, power them through the recorder’s built-in PoE ports, scan the QR code, and start viewing your system. No monthly fees, no cloud dependency, and no complicated software setup required.
SureVision recorders support a wide range of professional camera types, making it easy to build the right system for your property now and expand later with matching cameras that are built to work together.
Compatible SureVision Camera Types
Why This Matters
- Plug-and-play compatibility
- Faster installation and easier setup
- Cleaner remote viewing and playback experience
- Built to expand as your needs grow
- Designed for long-term professional use
Full Specifications — SV-NVR2P16-N
| Model | SV-NVR2P16-N |
| Included Storage | One pre-installed 4TB surveillance-grade hard drive |
| Decoding | |
| Decoding Format | Ultra 265, H.265, H.264 |
| Decoding Capability | Ultra 265/H.265: 2 × 16MP@30, 2 × 12MP@30, 4 × 4K@30, 6 × 5MP@30, 8 × 4MP@30, 10 × 3MP@30, 16 × 1080P@30 H.264: 2 × 16MP (4800×2688)@30, 2 × 12MP@30, 2 × 4K@30, 4 × 5MP@30, 6 × 4MP@30, 8 × 3MP@30, 14 × 1080P@30, 16 × 720P@30 |
| Capability Description | The resolution of each channel cannot exceed 8192 pixels in length and 4096 pixels in width. For VGA/HDMI independent output, the VGA live video is output by default. To output the highest resolution video from the HDMI port, clear the VGA video on the preview page. |
| Audio Compression | G.711A, G.711U |
| Network | |
| Incoming Bandwidth | 320 Mbps |
| Outgoing Bandwidth | 160 Mbps |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4 |
| Browser | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ |
| Video / Audio Input | |
| IP Video Input | 16-ch |
| RCA Audio Input | 1-ch |
| Video / Audio Output | |
| HDMI Output | 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| VGA Output | 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| RCA Audio Output | 1-ch |
| Liveview Display | 1 / 4 / 6 / 8 / 9 / 16 |
| Corridor Mode Screen | 3 / 4 / 5 / 7 / 9 / 10 / 12 / 16 |
| Two-Way Audio | |
| Two-Way Audio | 1-ch, RCA (using the audio input and output) |
| Snapshot | |
| FTP / Schedule / Event Snapshot | 4-ch snapshot (max. D1 (720 × 576) video resolution, with D1 snapshot resolution) |
| Recording | |
| Recording Resolution | 16 MP / 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080P / 960P / 720P / D1 / 2CIF / CIF |
| Synchronous Playback in Local | 16-ch |
| Smart | |
| Smart by IPC | All channels (up to 8 images/s in total): Face Detection, Face Comparison, Vehicle Detection (LPR), Temperature Detection, SIP, UMD, Video Metadata, Traffic Monitoring |
| VCA Search | Face Snapshot Search, Face Comparison Search, Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map |
| Alarm | |
| General Alarm | Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
| GUI Language | |
| Languages | 38 languages including English, Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian, and more |
| Hard Disk | |
| SATA | 2 SATA interfaces |
| Included Hard Drive | 4TB surveillance-grade hard drive, pre-installed |
| Capacity | Up to 24 TB for each HDD (maximum HDD capacity varies with environment temperature and hard disk size; environment temperature should not exceed 40°C) |
| Disk Group | Support |
| Redundant Storage | Support |
| Disk Array Type | RAID 1 |
| External Interface | |
| Network Interface | 1 RJ45 10 M / 100 M / 1000 M self-adaptive Ethernet interface |
| RS232 | N/A |
| Alarm In | 8-ch |
| Alarm Out | 2-ch |
| Power Supply | AC 100 to 240 V |
| Power Switch | Support |
| PoE | |
| PoE Interface | 16 RJ45 10 M / 100 M self-adaptive Ethernet interfaces |
| Max Power | Max 30 W for single port, Max 240 W in total |
| Supported Standard | IEEE 802.3at, IEEE 802.3af |
| Working Environment | |
| Working Temperature | -10°C to 55°C (14°F to 131°F) |
| Working Humidity | ≤ 90% RH (non-condensing) |
| Power Consumption (without HDD) | ≤ 20W |
| Weight (without HDD) | ≤ 2.6 kg (5.73 lb) |
| Dimensions | 380 mm × 322 mm × 53 mm (15.0" × 12.7" × 2.1") |
| Certification | |
| Certification | CE; FCC; UL; RoHS; WEEE |
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
| FCC | Part 15 Subpart B |
16 Channel SureVision NVR Questions
Does this SureVision NVR include a hard drive?
Yes. Every SV-NVR2P16-N includes a pre-installed 4TB surveillance-grade hard drive for local recording. Additional compatible storage can be configured when longer retention is needed.
How many cameras can this recorder support?
It supports up to 16 compatible IP cameras and includes 16 built-in PoE ports for direct compatible camera connections.
Can it record compatible 4K IP cameras?
Yes. The recorder supports compatible 4K and higher-resolution recording modes. Camera compatibility, total bandwidth, frame rate, decoding requirements, and storage should be confirmed when planning the system.
Does local recording require internet service?
No. The NVR can continue recording compatible cameras locally without internet service. Internet access is required for off-site viewing, remote alerts, and other internet-dependent features.
Are monthly cloud-storage fees required?
No required monthly subscription is needed for standard local recording to the installed hard drive or for compatible remote-viewing functions. Internet service and optional third-party services are separate.
Does RAID 1 work with the included 4TB drive?
The recorder supports RAID 1, but RAID 1 requires two compatible drives. The included 4TB drive provides standard local storage; add a second compatible drive when mirrored redundancy is required.
