SureVision Camera Features Video
SureVision NVR Features Video
16 Camera 4K Security Camera System (“Black Knight”) with 164 Foot Night Vision
This 16 camera SureVision IP security camera system, also known as the “Black Knight” system, gives you professional wired 4K surveillance with sixteen Black Knight 4K bullet cameras, a 16-channel SureVision NVR, Cat5e camera cables, remote viewing apps, local recording, and expert support — all with no monthly fees ever.
Your 16 camera SureVision (“Black Knight”) system includes a free 22-inch HD monitor, giving you a complete professional surveillance setup for viewing, recording, playback, and remote access.
Black Knight Camera & SureVision NVR Performance Highlights
A quick look at the most important Black Knight camera and recorder features before you review the full specifications below.
Black Knight Camera Features
- 8MP 4K Black Knight Bullet Security Cameras
- 2.8mm Wide Angle Lens
- Up to 164ft Infrared Night Vision
- Built-In Microphone
- Ultra 265 / H.265 / H.264 Compression
- Weatherproof IP67 Rated Housing
- 120dB Wide Dynamic Range
- Power Over Ethernet (PoE)
- ONVIF Profile S/G/T Support
SureVision NVR Features
- 16-Channel SureVision NVR Included
- 16 Camera Capacity
- 4K HDMI Display Output
- Remote Viewing — No Monthly Fees
- Ultra 265 / H.265 / H.264 Compression
- 320 Mbps Incoming Bandwidth
- 16-Channel Local Playback
- 2 SATA Hard Drive Bays
- Free 22-Inch HD Monitor Included
Black Knight 4K Bullet Cameras with Audio
The sixteen included SureVision (“Black Knight”) bullet cameras are built for broad business, warehouse, office, retail, school, church, and large-property surveillance coverage.
Each Black Knight camera provides 4K 8MP video, a 2.8mm wide-angle lens, built-in microphone, 164ft infrared night vision, WDR, PoE installation, and IP67 weatherproof protection.
SureVision 16-Channel NVR with Free Monitor
This 16 camera SureVision (“Black Knight”) system includes a 16-channel recorder and a free 22-inch HD monitor for local viewing and playback.
The SureVision NVR records locally, supports remote viewing, manages playback, and keeps you in control without required subscriptions or monthly cloud fees.
What This 16 Camera Security Camera System Includes & Does
This complete 16 camera SureVision (“Black Knight”) IP camera system includes everything you need to build a professional wired surveillance setup: sixteen 4K Black Knight cameras, SureVision NVR, pre-installed surveillance storage, Cat5e camera cables, free app access, a free 22-inch monitor, quick start guide, surveillance sign and stickers, and lifetime support.
The cameras capture video while the NVR records, stores, organizes, and manages your footage. You can watch live video, search recorded events, receive alerts, export evidence, and monitor your property remotely without monthly fees.
This system is ideal for businesses and larger properties that need wide professional 4K coverage from a complete wired security camera solution.
Everything Included With Your 16 Camera System
| Model: SV-BA8-B-N | |
| Camera | |
| Max Resolution | 8 MP |
| Sensor | 1/2.8" CMOS |
| Minimum Illumination | Color: 0.005 lux (F1.6, AGC ON), 0 lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto / Manual, 1 ~ 1/100000s |
| Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360° |
| S/N | >52 dB |
| WDR | 120 dB |
| Lens / DORI / Night Vision | |
| Focal Length / Iris | 2.8mm fixed lens, F1.6 |
| Field of View | 98.7° H / 53.9° V / 103.6° D |
| DORI Distance | Detect 285.1 ft; Observe 114 ft; Recognize 57 ft; Identify 28.5 ft |
| IR Distance / Wavelength | Up to 164 ft / 850 nm |
| Video / Image / Audio | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate | Main Stream: 8MP up to 20fps; 5MP, 4MP, 1080P, 720P up to 30fps. Sub Stream: 1080P, 720P, D1, 640×360, 2CIF, CIF up to 30fps. |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| Image Features | 2D/3D DNR, Smart IR, HLC, BLC, digital defog, privacy mask, ROI, OSD |
| Detection | Motion detection, ultra motion detection, tampering alarm, audio detection, cross line, intrusion |
| Audio | Built-in microphone; G.711U/G.711A audio compression; 64 Kbps / 8 kHz |
| Storage / Network / General | |
| Edge Storage | MicroSD up to 512 GB; ANR; NAS (NFS) |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, 802.1x, SNMP |
| Integration | ONVIF Profile S, Profile G, Profile T, API, SDK |
| Network Interface | 1 × RJ45 10M/100M Base-TX Ethernet |
| Protection | IP67, 4KV surge protection |
| Power | DC 12V ±25%, PoE IEEE 802.3af, max 6.9W |
| Dimensions / Weight | 190 × 73 × 71mm; 0.40kg |
| Material / Environment | Graphene + Metal; -30℃ to 60℃; humidity ≤95% RH non-condensing |
| Certifications | CE, FCC, UL/CUL, RoHS, WEEE |
| Model: SV-NVR2P16-N | |
| Decoding / Network | |
| Decoding Format | Ultra 265, H.265, H.264 |
| Decoding Capability | Ultra 265/H.265: 2×16MP@30, 2×12MP@30, 4×4K@30, 6×5MP@30, 8×4MP@30, 10×3MP@30, 16×1080P@30. H.264: 2×16MP@30, 2×12MP@30, 2×4K@30, 4×5MP@30, 6×4MP@30, 8×3MP@30, 14×1080P@30, 16×720P@30. |
| Audio Compression | G.711A, G.711U |
| Incoming / Outgoing Bandwidth | 320 Mbps incoming / 160 Mbps outgoing |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4 |
| Browser Support | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ |
| Video / Audio Input & Output | |
| IP Video Input | 16-channel |
| RCA Audio Input / Output | 1-channel RCA audio input / 1-channel RCA audio output |
| HDMI Output | 4K 3840×2160/30Hz; 1920×1080/60Hz; 1920×1080/50Hz; 1600×1200/60Hz; 1280×1024/60Hz; 1280×720/60Hz; 1024×768/60Hz |
| VGA Output | 1920×1080/60Hz; 1920×1080/50Hz; 1600×1200/60Hz; 1280×1024/60Hz; 1280×720/60Hz; 1024×768/60Hz |
| Live View Display | 1 / 4 / 6 / 8 / 9 / 16 |
| Corridor Mode Screen | 3 / 4 / 5 / 7 / 9 / 10 / 12 / 16 |
| Two-Way Audio | 1-channel RCA using audio input and output |
| Recording / Smart / Alarm | |
| Snapshot | 4-channel snapshot, max D1 video resolution with D1 snapshot resolution |
| Recording Resolution | 16MP / 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P / D1 / 2CIF / CIF |
| Synchronous Playback | 16-channel local playback |
| Smart by IPC | Face detection, face comparison, vehicle detection, LPR, temperature detection, SIP, UMD, video metadata, traffic monitoring |
| VCA Search | Face snapshot search, face comparison search, motor vehicle search, non-motor vehicle search, human body search, general search, people counting report, heat map |
| General Alarm | Defocus detection, scene change, object left behind, object removed, auto tracking, motion detection, tampering, human body detection, video loss, alarm input, audio detection |
| Alert Alarm | IP conflict, network disconnected, disk offline, disk abnormal, illegal access, hard disk space low, hard disk full, recording/snapshot abnormal |
| Storage / Interface / PoE | |
| SATA / Capacity | 2 SATA interfaces; up to 24TB per HDD bay |
| Disk Group / Redundant Storage | Supported |
| Disk Array Type | RAID 1 |
| Network Interface | 1 RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| Alarm In / Out | 8-channel alarm input / 2-channel alarm output |
| PoE Interface | 16 RJ45 10M/100M self-adaptive Ethernet interfaces |
| PoE Power | Max 30W per port, max 240W total |
| PoE Standard | IEEE 802.3at, IEEE 802.3af |
| Environment / Certification | |
| Power Supply | AC 100 to 240V, power switch supported |
| Working Temperature / Humidity | -10°C to 55°C; ≤90% RH non-condensing |
| Power Consumption | ≤20W without HDD |
| Weight / Dimensions | ≤2.6kg; 380mm × 322mm × 53mm |
| Certifications | CE, FCC, UL, RoHS, WEEE |
