SUREVISION IP Camera NVRs
Network Video Recorders are the most important part of any high quality IP surveillance system. Take advantage of our high-end, commercial-grade SUREVISION IP Camera NVRs at CCTV Security Pros to enjoy HD video quality live over the internet. Our full-featured and affordable IP camera recorders now offer up to 4K video resolution with multiple hard drive options that can be expanded for a flexible solution that fits your surveillance recording needs. Our SUREVISION IP NVR line is ONVIF compatible. SUREVISION is our latest and greatest line of IP Cameras. Order a SUREVISION IP NVR and treat yourself to a crystal clear, user friendly video recorder. View your cameras over the Internet, tablets, and cell phones as easy as 1-2-3.
SUREVISION "Green Line" Video Surveillance Recorder Highlights:
- Remote Viewing on PC, Cell Phone, and Tablet
- Industry Latest and Greatest
- Up to 4K Recording and Playback
- Motion 24/7 or on Motion Detection Mode
- Quick Start Guide Included for Easy Set Up
- 3 Year Warranty
- Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
- Free Unlimited USA Support
TECHNICAL SPECIFICATIONS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Video/Audio Input | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IP Video Input | 8-ch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Two-way Audio Input | 1-ch, RCA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Incoming Bandwidth | 320Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Outgoing Bandwidth | 160Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Remote Users | 128 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS,DNS,DDNS,SNMP,SMTP,NFS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser | IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video/Audio Output | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HDMI/VGA Output | VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz,1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI: 4K (3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | 1-ch, RCA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711A, G.711U | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Synchronous Playback | 8-ch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Live View Display | 1/4/6/8/9 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Corridor Mode Screen | 3/4/5/7/9 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Snapshot | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
FTP/Schedule/Event Snapshot | 16-ch snapshot, up to 1080P resolution | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Format | Ultra 265, H.265, H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Live View/Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Capability | 1 x 12MP@30, 2 x 4K@30, 5 x 4MP@30, 8 x 1080P@30 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hard Disk | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SATA | 2 SATA interfaces | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Capacity | up to 10TB for each HDD | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
eSATA | NA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Disk Group | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VCA Detection by Camera | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VCA Search | Behavior Search, Vehicle Search | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
People Counting | People Flow Counting, Crowd Density Monitoring | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Intrusion Prevention (SIP), Vehicle Detection by Camera | Total 8-ch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Alarm | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Input Alarm, Audio Detection | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alert Alarm | IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
External Interface | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Interface | 1 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB Interface | Front panel: 1 x USB2.0,Rear panel: 1 x USB3.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS232 | NA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS485 | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm In | 8-ch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Out | 2-ch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface | 8 RJ-45 10M/100M self-adaptive Ethernet Interface | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max Power | Max 30W for single port Max 130W in total |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Supported Standard | IEEE 802.3af/at | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 100~240V AC Power Consumption: ≤ 15W (without HDD) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Environment | -10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions (W×D×H) | 380mm × 315mm × 53mm (15.0" × 12.4"× 2.1") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Weight (without HDD) | ≤2.6Kg (5.73lb) |
NVR FEATURES
- 4K Ultra High Definition
- 8 PoE Camera Inputs
- Remote Viewing – No Monthly Fees
- H.265 High Video Compression
- 320 Mbps Incoming Bandwidth
- HDMI and VGA Display Output
- 2 Hard Drive Bays
